Phone Features

Phone Features



MAKING A CALL
  1. Take the Handset/Headset off-hook or press the Speaker button or an available LINE key (activates speakerphone).
  2. The line will have dial tone, and the corresponding line's LED will turn green.
  3. If you wish, select another LINE key (Alternative SIP account).
  4. Enter the phone number, then your PIN, followed by the # key.
  5. Press the SEND button or press the "DIAL" key

REDIAL
  1. Take the phone off the hook.
  2. Press the SEND button or press the “REDIAL” soft key.

ANSWERING CALLS
  1. Single Incoming Call:
    1. Answer the call by taking the Handset/Headset off-hook, pressing SPEAKER, or pressing the corresponding account LINE button.
  1. Multiple Incoming Calls:
    1. When there is a call waiting, users will hear a Call Waiting tone.
    2. The next available line will flash red.
    3. Answer the incoming call by pressing its corresponding LINE button.
    4. The current call will be put on hold.
    5. Toggle between the calls using the LINE button.
ENDING A CALL

  1. End a call by pressing the “End Call” soft key or hang up the phone.

CALL HOLD/RESUME
  1. Hold: Place a call on 'Hold' by pressing the hold button.
  2. Resume: Resume a call by pressing the corresponding blinking LINE.

PARKING
  1. Parking a call: While on the call Press #74, the system will readout a Parking No.
  2. Picking up a Parked call: Dial the Parking No.
Call Transfer
Info
Assuming that you are in a call and wish to transfer the call to another party.
  1. Blind Transfer
    1. Press transfer button.
    2. Dial the number and press the send button to complete transfer of active call.
  2. Attended Transfer
    1. Press an idle line key to make a new call and the active LINE will be placed on hold automatically.
    2. Once the call is established, press transfer button followed by the LINE button of the held line to transfer the call.
    3. After the call is transferred, phone will display idle screen.
  3. Auto-Attended Transfer:
    1. Set "Auto-Attended Transfer" to "Yes" on Web GUI.
    2. Establish one call first. Press transfer key to bring up a new line, and the first call will be placed on hold automatically.
    3. Dial the number and press SEND button to make a second call.
    4. Press transfer key again to make the transfer.
NotesNote: For Auto-Attended Transfer, after dialing out the number for the second call, a “Split” soft key will show. If the second call is not established yet (ringing), pressing “Split” will hang up the second call. If the second call is established (answered), pressing “Split” will resume the second call and keep the first call on hold.

3-WAY CONFERENCE

Initiate a Conference Call:
Info
Assuming that you are already in a conversation and wish to bring a third party together in a 3-way conference.
  1. Press conference button to bring up conference dialing screen.
  2. Dial the third party number followed by SEND key.
  3. When the call is established to the third party, press the “ConfCall” soft key to initiate 3way conference.
Cancel a Conference Call
  1. Press “Cancel” soft key in conference dialing screen to resume the two-way conversation.
Hold The Conference:
  1. Press hold button to hold the conference call with all parties are on hold;
  2. Press “ReConf” soft key to resume conference call; or select the corresponding blinking LINE to speak with an individual party.
End The Conference:
  1. The conference will be terminated for all three parties if the conference initiator hangs up or presses “EndCall” soft key.
VOICEMAIL MESSAGE
InfoNotes
A blinking red MWI (Message Waiting Indicator) indicates a message is waiting.
  1. Press the Message button to retrieve the message. An IVR will prompt the user through the process of message retrieval.
  2. Press a specific LINE to retrieve messages for a specific line account.
NotesNote: Each account requires a voicemail portal number to be configured in the “voicemail user id” field.

MUTE/DELETE

  1. Press the MUTE button to mute/unmute the microphone.
  2. The Mute icon indicates whether the microphone is muted.
VOLUME ADJUSTMENTS
  1. Use the volume button to adjust the ring volume when the phone is idle.
  2. Press the volume button during an active call to adjust the call volume.
PICKUP EXTENSION
  1. To pick up a call from another extension dial *5 + Extension Number.
